CLT Acacia Panels

INCLT.id Standard CLT panels

Product Data Sheet: CLT Acacia panels

– Wood Specie : Acacia Mangium
– Dimensions : 2400 x 1200 & 3600 x 1200
– m2 : 2400 = 2,88m2 & 3600 = 4,32m2
– Thickness: 51 / 59 / 67 / 75 in 3 layers
– Costin: Cost calculation is based on m3
– Lamel: All components (lamel) are made to measure
– Press: Approx applied pressure 320kg per square centimeter
– Gluing: With Aqueous polymers and isocyanate adhesive
– MC : [±2%] 12% Moist content
– Movement: Along the panel ±0,01% moisture change
– Weight: With a density of 550kg/m3 and 650kg/m3
– CNC cut: Rectangular cut with a standard Radius of 20mm
– CNC: Tolerance applied in-plane & perpendicular surface of ±1mm
– Grain: Direction outer layers run along the panel length
– Sanding: Surfaces in grades 150 – 180, or per request
– Surfaces

: A – visual quality
: B – industrial visual quality
: C – non-visual quality
